Electric Cold Isostatic Press With 80mm ID Die

CIP-80MAF Electric Cold Isostatic Press is to place the product in a tightly closed container filled with liquid, and after connecting to power supply, the liquid applies equal pressure onto each side of sample surface. With the advancement of science and technology and our company's further research on powder materials, isostatic presses are more and more widely used in the forming of powder metallurgy, composite materials, refractory materials, ceramics, cemented carbide / high-strength alloy and other materials.

Brand: Shenyang Kejing
Product origin: Shenyang, China
Delivery time: 22 working days
Supply capacity: 50 sets

Information

Product Introduction
The CIP-80MAF Electric Cold Isostatic Press is widely used for forming materials such as powder metallurgy, composite materials, refractory materials, ceramics, and hard alloys. This series features a split-type structure and is equipped with an LCD touchscreen control interface. After entering the mold cavity diameter, the system automatically calculates the pressure applied to the sample.

The pressurization process is fully program-controlled and provides two operating modes: standard pressurization and advanced multi-stage program pressurization, allowing flexible adaptation to the processing requirements of different samples.

Main Features

· The machine uses an LCD display, and the pressurization process is automatically controlled, including program-controlled pressurization, pressure holding, and timed pressure release.

· After entering the mold cavity diameter, the system automatically converts and displays the pressure applied to the sample.

Technical Parameters

Product Name	CIP-80MAF Electric Cold Isostatic Press
Product Model	CIP-80MAF
Technical Parameters (Specification)	1. Working Voltage: AC220V, 50/60Hz 2. Rated Power: 1500W 3. Rated Pressure Range of Electric Press: 0–150 tons (max) 4. Diameter of Press Cylinder Piston: Φ250 mm 5. Stroke of Press Cylinder Movement: 0–50 mm 6. Working Space Dimensions: 260 × 410 mm 7. Standard Pressurization Program: Slow pressurization – pressure holding – automatic pressure release 8. Multi-stage Pressurization Program: Multi-stage programmable pressurization with real-time graphical display during operation 9. Pressure Holding Time: 0–999.59 seconds 10. Pressure Conversion: The system automatically converts pressure based on the preset sample shape and dimensions 11. Display & Operation Mode: Keypad + touch screen 12. Internal Cavity Size of CIP Mold: Φ80 × 158 mm 13. External Dimensions of CIP Mold: Φ240 × 385 mm (Note: Height includes upper punch) 14. Maximum Pressure Endurance of CIP Mold: 155 tons (500 MPa)
	15. Product Specifications: · Dimensions: 950 × 500 × 1180 mm · Weight: Press: ≈650 kg Mold: ≈90 kg
