Electric Cold Isostatic Press With 30mm ID Die (Max.500 Mpa)
500CIP-30MA Ultra-high Pressure Cold Isostatic Press is to place the product in a tightly closed container filled with liquid, and after connecting to power supply, the liquid applies equal pressure onto each side of sample surface.With the advancement of science and technology and our company's further research on powder materials, isostatic presses are more and more widely used in the forming of powder metallurgy, composite materials, refractory materials, ceramics, cemented carbide / high-strength alloy and other materials.
- Shenyang Kejing
- Shenyang, China
- 22 working days
- 50 sets
- Information
Product Introduction
The 500CIP-30/50/60MAF Series Ultra-High Pressure Cold Isostatic Press (CIP) is widely used for forming materials in powder metallurgy, composite materials, refractory materials, ceramics, and cemented carbides. This series adopts a split-structure design and is equipped with an LCD touch-screen control interface, which automatically calculates the pressure applied to the sample after the mold cavity diameter is entered.
The pressurization process is fully automated, offering Standard Pressing Mode and Advanced Multi-Stage Pressing Mode, allowing flexible adaptation to different sample processing requirements.
Technical Specifications
· Rated pressure range of the electric press: 0–40 tons (max)
· Press cylinder piston diameter (d): Φ130 mm
· Cold isostatic press mold inner cavity size: Φ30 × 167 mm
· Mold external dimensions: Φ97 × 258 mm (Note: height includes upper punch)
· Maximum allowable pressure of the isostatic mold: 36 tons (500 MPa)
The 500CIP-30/50/60MAF series delivers reliable pressure control, intuitive operation, and high versatility, making it an ideal solution for high-precision forming applications in research and industrial fields.
Main Features
1. Easy Operation: Supports automatic pressure conversion and programmable pressurization, ideal for high-end laboratory applications.
2. Compact Design: Small footprint while delivering high-pressure performance; excellent cost-effectiveness suitable for various laboratory environments.
3. Enhanced User Interface: Equipped with a 7-inch high-definition color touchscreen with an intuitive and clear interface for significantly improved ease of use.
4. Simple Maintenance: Split-structure design allows easy transport and cleaning, reducing overall operating cost.
Technical Parameters
Product Name | 500CIP-30MA Ultra-high Pressure Cold Isostatic Press |
Product Model | 500CIP-30MA |
Technical Parameters (Specification) | 1. Working Voltage: AC 220V, 50/60 Hz 2. Rated Power: 1500 W 3. Structure Type: Electric, integrated unit 4. Rated Pressure Range of Electric Press: 0–40 tons (max) 5. Piston Diameter of Press Cylinder (d): Φ130 mm 6. Press Cylinder Stroke (T): 0–50 mm 7. Working Space (M×N): 170 × 390 mm 8. Standard Pressurization Program: Slow pressurization – pressure holding – automatic pressure release 9. Multi-segment Pressurization Program: Multi-stage pressurization with real-time graphical display 10. Pressure Holding Time: 0–999.59 seconds 11. Pressure Conversion: Automatic pressure calculation based on the set sample shape and dimensions 12. Display & Operation: Buttons + touchscreen 13. Isostatic Mold Inner Cavity Size: φ30 × 167 mm 14. Isostatic Mold Outer Dimensions: Φ97 × 258 mm (height includes upper punch) 15. Maximum Bearing Pressure of Isostatic Mold: 36 tons (500 MPa) 16. Product Specifications:
|
Warranty
One year limited with lifetime support (not including rusted parts due to inadequate storage conditions)
